i-flex RF attenuators are used in a wide variety of applications and are a perfect fit to any solution where a reduction in power is required. i-flex RF attenuators offer superior performance and low VSWR (return loss), which minimises signal reflections and simultaneously reduces the ripple effects in the output frequency response. This assures flat, consistent attenuation characteristics regardless of other device’s reflection characteristics. i-flex RF attenuators are manufactured using state of the art resistive elements in a conventional series circuit. i-flex RF attenuators are rugged, and are only marginally affected by the ambient temperatures and humidity changes. The i-flex RF attenuators are available with customised attenuation values, PIM rating and power factors. The DC-3GHz and DC-6GHz offered frequency range ensures the broadest attenuation & frequency coverage available.

Features

• Outstanding electrical performance.
• Covers frequency range from DC up to 6GHz available for both DIN 7-16 connector type and N
  connector type.
• Low attenuation tolerance.
• Up to 200 W power capacity.
• Low VSWR.
• PIM rating ≤ -160dBc.

Applications

• Used in order to reduce the signal power level in small buildings, hospitals and stadiums.
• Suitable for reducing signal power level at BTS output and stabilise the signal as per design
  requirement.

*All RF Attenuators are available with Male and Female gender combination in 4.3-10 connector type

* RF Attenuators also available with other PIM ratings

*RF attenuators are available with customized attenuation values and power ratings with below mentioned connector combinations:

N-Female to N-Femlae, N-Male to N-Female, DIN-Male to DIN-Male, DIN-Female to DIN-Female, DIN-Male to DIN-Female
